compute system:

Mounting Options

• Wall mount and table stand

Cpu

• Intel i7-8550U

Memory

• 4GB RAM

Storage

• 128GB SSD

Wireless Data Network

• WiFi (802.11 AC) 2.4GHz/5GHz
• Bluetooth 4.2, Ethernet (PoE)

Ports

• 2x HDMI 1.4 output with CEC
• 1x HDMI 1.4 input video port
• 5x RJ45 Ethernet ports
• 3x Type-A and 1x Type-C USB ports
• 1x headphone jack w/ mic support (3.5 mm)

Dimensions

• 135 x 284 x 29 mm

Smart Camera:


• 12 MP 1/2.3” CMOS Sensor
• Up to 1080p @ 30 fps
• f/2.8 aperture

Optics

• Ultra-wide angle glass optics
• 120˚ horizontal field of view

Connection

• Ethernet (PoE)

Dimensions  (LxWxH)

• 84 x 107 x 42 mm

Mic pod  – (included in medium and large kits only)

Microphone

• 8 element, circular beamforming array
• 100Hz-24kHz pickup

Connections

• 1x Daisy Chain input port for data and power (up to 4 mic pods)
• 1x Daisy Chain output port for data and power (up to 4 mic pods)

Range

• Optimal pickup range of up to 2m

Dimensions  (L X W X H)

• 95 x 95 x 30 mm

Smart Audio Bar

Speaker

• 20W RMS power
• 80Hz-24kHz frequency response

Microphone

• 8 element, linear beamforming array
• 100Hz-24kHz pickup

Audio Performance

• AEC, ANC, and TrueVoice™ multi-channel noise cancellation

Connections

• 1x USB-C with USB 2.0 UAC
• 1x stereo analog RCA output (for assistive listening devices)
• 1x Ethernet (PoE)
• 2x RJ45 (daisy chain output data and power)

Range

• Optimal pickup range of up to 4m

Dimensions

• 95 x 705 x 133 mm

Controller – touch controller  (included in medium and large kits only)

Display

• 10.1” anti-smudge touchscreen
• Color sensor
• Orientation sensor

Resolution

• 1280 x 800 x 3(RGB) LCD with Optically Bonded multi-touch screen

Connection

• 1x 10Gb PoE connector

Dimensions (L X W X H)

• 164 x 245 x 91 mm
