Yamaha Revolabs FLX UC 1000
Stock status: Call to check Availability
Interface
- Mini USB 2.0 Connector, Power over ethernet (PoE)
Power source
- IEEE 802.3af Power over Ethernet (PoE)
Operating environment
- Temperature: 0 to 40° C (32 to 104° F), Humidity: 20 to 85% (no condensation)
Dimensions
- Base Unit: 150 (W) x 123 (H) x 150 (D) mm (5.9 (W) x 4.84 (H) x 5.9 (D) in),
- Dialer Unit: 133 (W) x 41 (H) x 136 (D) mm (5.2 (W) x 1.6 (H) x 5.3 (D) in)
Weight
Accessories
- USB cable 2 m (6.56 ft.), Ethernet Cable, 25 ft (7.62 m), Quick Start Guide
Other
Audio
Microphones
- 4 embedded directional, 360° Audio Pick-Up
Speakers
Maximum volume
- Momentary maximum: 91 dB (1 m)
Frequency bandwidth
- For sound pickup: 160 Hz – 16,000 Hz, For playback: 160 Hz – 20,000 Hz
Signal processing
- Adaptive echo canceller, Noise reduction
SIP – Number of Lines
- 3+1 Lines: Up to 2 SIP calls, 1 USB call, plus the user
Codes
- G.711 (A-law and μ-law), G.722, G.726, G.729
Security
- SRTP/SRTCP Support (RFC 1889), IETF SIP support (RFC 3261 and companion RFCs), SSIP, Password protected configuration files, Password protected login, HTTPS Secure Provisioning
Others
- Call Handling: Make Call, Answer, Hold, Resume, Transfer (Blind and Supervised), Forwarding, Do not disturb, Redial, Call Timer, Call ID, Speed Dial, Missed Call Notifications, Voice Mail Notifications (switch-configured). Call Bridging: Supports Bridging SIP and USB Calls. Join, Split, Hold, Resume. DTMF Support: RTP event, SIP in-band, SIP info package support. Network Provisioning: DHCP or Static IP, Server Based Central Provisioning, Web Portal for Individual Unit Configuration
